Control of Gene Expression思维导图
基于基因表达调控的进化模型详述
树图思维导图提供 Control of Gene Expression 在线思维导图免费制作，点击“编辑”按钮，可对 Control of Gene Expression 进行在线思维导图编辑，本思维导图属于思维导图模板主题，文件编号是：eb527262127a1e506d455d1e3a7db0b7
思维导图大纲
Control of Gene Expression思维导图模板大纲
prokaryote
Gene expression
information from genes
synthesis of a functional gene product
features
almost all cells contain a full DNA complement
selectively express
reason--changes in internal and external signals
prolaction (from pituitary gland)
mammary gland, lactation stimulate
transcription of genes for milk proteins
housekeeping genes are expressed in all tissues
consistently expressed across tissues and developmental stages
maintain basic cellular function
basic metabolism
cellular transport
cell cycle
expression--tissue-dependent
could be changes in response to the same stimuli
could be changes in response to the multiple stimuli
IFNγ + Tet
Regulation
operon
basic mechanism for the control of gene expression in prokaryote
promoter
short region of DNA
beginning of transcription of a gene by RNA polymerase
typically located directly upstram of the transcription initiation site
operon
cluster of genes
transcribed from the same promoter
give a single mRNA carrying multiple coding sequences
operator
short DNA region
adjacent to the promoter of a bacterial operon
binds repressor/activator proteins
in response to controlling the rate of transcription of the operon
Negative/positive control system
tryptophan (trp) operon
regulation of enzyme activity
precursor
enzyme 1
trp E
trp D
enzyme 2
trp C
enzyme 3
trp B
trp A
tryptophan
tryptophan absent
repressor inactive
operon on
tryptophan present
repressor active
inhibt own production by activating the repressor protein
operon off
the tryptophan binds to the operator, blocking transcription
lac operon
子主题 2
lactose operon( inducible operon)
no lactose
lactose present
lactose present, glucose absent
E.Coli growth
on glucose
on glucose and lactose
new enzymes are synthesized
isopropylthiogalactoside
synthetic inducer
no hydrolyzed by β-galactosidase
most commonly used in recombinant protein expression in E.Coli
eukaryote
transcription
histone binding
decrease the probability of RNA synthesis
histone modification
histone tails normally have positive charge
binding to negatively charged DNA on other nucleosomes
Acetylation cause his tone tails to lose positive charge
heterochromatin
euchromatin
DNA methylation
DNA structure change
Decrease RNA synthesis probability
Methylation signals acetylation removal
Decrease RNA synthesis probability
Methylations can be inherited, causing epigenetic inheritance
post-transcriptional processing
5' cap and poly-A tail
Increase protein synthesis probability
Alternative splicing
May increase or decrease the protein synthesis probability
transcription initiation regulation
DNA components
Protein components
May increase or decrease the protein synthesis probability
post-transcriptional processing
cause RNA degradation
5' caps or poly-A tails not correct
Unused exons/introns
miRNA
Decrease Protein synthesis probability
protein degradation
ubiquitination
degron sequence
Phosphoylated
After functioning
Used to recruit the ubiquitous liase that adds ubiquitin
